CXA1507 1512 CRI98 110LM W 24W 30W 12W High Cri LED Chip

Name: CXA1507 1512 CRI98 110LM W 24W 30W 12W High Cri LED Chip
Brand: XUANCAI
Price: 0.5 USD

Buy cheap CXA1507 1512 CRI98 110LM W 24W 30W 12W High Cri LED Chip product

Brand Name : XUANCAI

Model Number : CL-23.85*23.85/21 LED COB CHIP

Certification : CE ROHS LM-80

Place of Origin : China

MOQ : 100

Price : $0.5- $2.9

Payment Terms : T/T, Western Union, Paypal , Alibaba trade assurance

Supply Ability : 10000M / Month

Delivery Time : 3-5 days

Packaging Details : Blister box packaging

Product Name : CL-23.85*23.85/21 LED COB CHIP

Watt : 30w

Current : 600-750mA

Voltage : 36-39v

Applicant : Commercial lighting / Indoor light

Life Span : 50000 hours

Chip Brand : US Bridgelux

Certificate : CE ROHS LM-80

CRI : >98

Lumens : 110-120lm/W

Contact Now

CXA1507/1512 Size High CRI RA>98 100-110LM/W 12W 18W 30W LED COB Chip for Commercial Lighting US Bridgelux

Product Information

Product Name	CL-23.85*23.85/21MM LED COB CHIP
Power	30w
Current	750mA
Voltage	36-39v
CRI	>98
Lumens	110-120lm/W
Chip Brand	US Bridgelux
Color Temperature	2700-6500k
Warranty	3 years

Feature

◆Mechanical Dimensions : CL-23.85*23.85/21 led cob chip

◆Package Structure :Aluminium Base Chip

◆CRI(Ra):MIN 98

◆Nominal CCT :2,700K,3,000K,3,500K,4,000K,5,000K,6,000K, 6500K

◆Chromaticity Range : 3-step MacAdam Ellipse

◆RoHS CE LM-80 compliant

◆Better die arrangement for optics

Applications

◆Tracking Light, Spot Light, Par Light, Bulb Light, Down Light

Product Features

High lighting refers to the bright color of RA 98, which restores the color of the object itself and further

improves the optical uniformity

Applications

CXA1507 1512 CRI98 110LM W 24W 30W 12W High Cri LED Chip

Trade Show

CXA1507 1512 CRI98 110LM W 24W 30W 12W High Cri LED Chip

Product Tags:

CXA1507 12W High Cri LED Chip

CXA1507 High Cri LED Chip

CXA1507 Cri 98 Led cob
