Diving light Cob Led Rgbw

Name: Diving light Cob Led Rgbw
Brand: XUANCAI
Price: 3.1 USD

Buy cheap Diving light Cob Led Rgbw product

Brand Name : XUANCAI

Model Number : XC-36*36/28

Certification : CE ROHS LM-80

Place of Origin : China

MOQ : 100

Price : $3.1-$5.9/PCS

Payment Terms : T/T, Western Union, Paypal , Alibaba trade assurance

Supply Ability : 10000M / Month

Delivery Time : 3-5 days

Packaging Details : Blister box packaging

Product Name : XC-36*36/28 RGBW

Power : 25W

Current : 600mA / 300mA / 300mA / 300mA

Voltage : 20-21V / 19-20v / 17-18v / 20-21V

CRI : 90

Color temperature : RED/BLUE/GREEN/4000K

Applicant : Diving light

Life span : 50000 hours

Material : Aluminium

Contact Now

LED COB RGBW chip 36*36/28 25w for Diving light special lights, power color can be customized

Product Description

Mechanical Dimensions: 36.0x36.0x1.7(mm)

CRI(Ra):Min.90

◆RoHS compliant

◆Package Structure:Aluminium Base Chip on Board

◆Nominal CCT:4,000K

◆Better die arrangement for optics

◆Wide range of luminous fluxand high efficacy

Chromaticity Range: 3-step MacAdam Ellipse

Product Specification

Product Name	XC-36*36/28 RGBW
Power	25w
Current	300mA+ 300mA+ 300mA+600mA
Voltage	19-20v+17-18v+20-21v+ 20-21v
CRI	90

Absolute Maximum Ratings

Parameter	Symbol	Rating
Forward Current	I_F	1500mA
Reverse Current	I_R	1mA
Operating Temperature	T_OPR	-30℃ To +75℃
Storage Temperature	Tst	-30℃ To +75℃
Case Temperature	Tc	85℃
Junction Temperature	T_J	125℃
Soldering Temperature	T_SOL	350℃± 10℃ For 5 Seconds
ESD Sensitivity	ESD	2000V HBM

Reliability Test

No.	Test Item	Test Condition	Test Cycle
1	Continuous Operation Test	Tc=85℃ IF=1200mA	1000H
2	Low/High Temperature Storage Test	-40℃/30min~ +100℃/30min	100 Cycles
3	High Temperature Storage Test	Ta=100℃	1000H
4	Low Temperature Storage Test	Ta=-40℃	1000H
5	Moisture-proof Test	Tc=60℃ ,95%RH	1000H

Applications

Diving light Cob Led Rgbw
