Food Bread Fresh Fruit Vegetable 6000K Special Color Led Cob

Name: Food Bread Fresh Fruit Vegetable 6000K Special Color Led Cob
Brand: XUANCAI
Price: 1.2 USD

Buy cheap Food Bread Fresh Fruit Vegetable 6000K Special Color Led Cob product

Brand Name : XUANCAI

Model Number : XC-19*19/17

Certification : CE ROHS

Place of Origin : China

MOQ : 100

Price : $1.2- $ 3.9

Payment Terms : T/T, Western Union, Paypal , Alibaba trade assurance

Supply Ability : 10000M / Month

Delivery Time : 3-5 days

Packaging Details : Blister box packaging

Product Name : XC-19*19/17 Bread Light

Watt : 20-50w

Current : 500-1200mA

Voltage : 36-39v

CRI : >95

Chip Brand : Bridgelux

Certificate : CE ROHS, LM-80

Color temperature : 2700-6000K

Application : Food Bread / Fresh Fruit / Vegetable

Contact Now

Commercial special color light designed for Food Bread / Fresh Fruit / Vegetable COB LED Chip 19*19/17

Product Specification

Product Name	XC-19*19/17 Bread Light
Power	20-50w
Current	500-1200mA
Voltage	36-39v
CRI	>95
Application	Bread Light
Color Temperature	2700-6500k

Product Characteristics

XC 19 17-M 12 08-C 27 90-C 3 1

[1][2][3][4][5][6][7][8][9][10][11][12]

[1]:Company abbreviation

[2]:Product Size

[3]:Luminescent surface

[4]:Optical effect level

[5]:Number of LED chips in Series

[6]:Number of LED chips in parallel

[7]:Color category

[8]:Nominal CCT

[9]:Color index

[10]: Light range

[11]:Chromaticity Range

[12]:Type of substrate

Electro Optical Characteristics

Product Code	Nominal CCT	CRI(Ra)		Luminous Flux(lm)		Efficacy ( lm/W )	Forward Current (mA)	Voltage (V)
		Ra	R9	Luminous Flux(lm)		Efficacy ( lm/W )		Voltage (V)
		Min.	Min.	Min.	Typ.	Typ.		Min.	Typ.	Max.
XC1917-M1208-C2790-C31	2700K	90	50	4912	5150	112	1200	36	37	38

Absolute Maximum Ratings

Parameter	Symbol	Rating
Forward Current	I_F	1800mA
Reverse Current	I_R	1mA
Operating Temperature	T_OPR	-30℃ To +75℃
Storage Temperature	Tst	-30℃ To +75℃
Case Temperature	Tc	85℃
Junction Temperature	T_J	125℃
Soldering Temperature	T_SOL	350℃± 10℃ For 5 Seconds
ESD Sensitivity	ESD	2000V HBM

Applications

Food Bread Fresh Fruit Vegetable 6000K Special Color Led Cob

User Manual

Storage

To avoid moisture, we recommend storage conditions for the unopened LED +5 ~ +30℃

rela-tive humidity <60%. LED should be used within 168 Hrs. of opening the package. Please make sure to dehumidify and vacuum pack the remaining/ unused LED. Dehumidifying condition: +120℃±5℃ of 4Hrs. Effective age for the sealed led is one year.
